Quick Release Mooring Pulley

Quick Release Mooring Pulley

Conventional Quick Release Mooring Hooks are not always the right solution for mooring issues. When limited space is an issue, the Quick Release Mooring Pulley could offer a solution.

A Quick Release Mooring Pulley is used to reduce the amount of fixed mooring points: instead of two conventional Quick Release Mooring Hook Units only one Pulley is needed. The mooring line will run from the moored vessel to the pulley where it will be looped back to the vessel where it will be secured on the vessel’s deck bits. This saves space on the deck of the vessel: only one winch is needed to create two mooring lines.

With the Quick Release Mooring Pulley the force concentration on each rope is equalized because the friction in the sheave rotation is minimized.

Brochure download

Read more about Berthing & Mooring in our brochure.


Optional features for the Quick Release Mooring Hook:

  • Integral capstans
  • Remote control system
  • Mooring load monitoring system
  • Electrical insulation
  • Anti-rope slip devices (keepers)
  • Special coatings
  • Special low temperature executions
  • Customized designs

Safe monitoring with Mooring Load Monitoring System (MLMS)

With the Mooring Load Monitoring System a close and constant watch on the forces on the mooring lines is kept. You can take immediate action in possible slack or overload situations. Load information is displayed in real time and alarms can be preset upon Safe Working Load requirements.

With the retrieved data the number of mooring lines required for safe mooring can be estimated. This information on is accessible through different portable devices such as PDA’s and pagers.

Remote Control Systems (RCS)

In case of an emergency you can release the hooks from a distance by remote control. With the Remote Control System the hooks can be released individually or simultaneously. Open or closed hook indications can be transmitted to the remote control panel or displayed on iMoor application software. We offer the following remote control system:

Hydraulic Remote Control System: The release mechanism of the hook is operated by a hydraulic cylinder mounted on the hook. Hydraulic pressure is provided by a hydraulic power pack fitted on each mooring unit.

The system operates with a Remote Control Panel. There are several in- and outdoor configurations including pushbutton panels, virtual panels on computer screen and ATEX certified panels. These panels are explosion proof.

Mampaey benefit: we customize your product

Mampaey Offshore Industries is specialized in customizing the products to the costumer’s demands. Mampaey also revamps and upgrades existing jetties. The products can be customized for Low Temperature Environments, Coal, Iron Ore Applications, etcetera.

Mooring Pulley
Mooring Pulley
